Why Low
Profile Prime XP
The Low Profile Prime
XP is compact with a height of only 2.06"" for a universal fit with double
the light output of the 3 watt Low Profile Bar. The Low Profile Prime XP Series
also makes use of Prime Drive Technology which manages heat levels to prolong
the life of the LEDs.
Prime Drive - The Smart LED Bar
Electronic Thermal Management
ETM monitors the heat output of the LEDs and makes use of
integrated Pulse Width Modulation circuitry in order to maintain safe operating
temperatures in order to prolong the LED life span to its full 50,000 hour
potential.
Pulse Width Modulation
The Low Profile Xmitter Xtreme utilizes integrated Pulse
Width Modulation (PWM) dimming circuitry to manage heat levels. PWM works by
flashing the LED at a frequency faster than the human eye can detect, reducing
the time that the LED is operating while still delivering 100% light output.
Bold, Strong Design- The Tough LED Bar
Extruded 6061 Aluminum
The Low Profile Xtreme features a 6061 extruded aluminum
housing for ultimate strength and durability.
IP-68 Rated
The Low Profile Xtreme has achieved an ingress protection
rating of IP-68, signifying that it is dust-proof and submersible in water up
to 3 meters.
Proven Mounting System
The Low Profile Xtreme utilizes the Vision X signature
stud mounting system that allows for 15° of adjustability and helps to control
vibration through the use of isolated rubber in the mount.
Key
INCLUDED |
•Low Profile Xtreme |
SPECIFICATIONS |
|
WARRANTY |
Extended |
AVAILABLE
HOUSING COLOR |
Black or White |
MOUNTING
DEPTH |
1.00" |
LED
LIFESPAN |
50,000 |
TECHNICAL
DETAILS |
|
HEIGHT |
2.06" |
DEPTH |
2.45" |
OPTIC
PURITY |
90% |
DRIVEN
AT |
90% |
INPUT
VOLTAGE |
9-32V DC |
IP
RATING |
IP-68 |
VIBRATION
RATING |
15.6G |
OPERATING
TEMPERATURE |
-40 Celsius ~ +80
Celsius |
ADDED
FEAUTRES |
• Weatherproof Deutsch
Connector with Plug-and-Play Harness |
